FUTABA 7PXR User Manual

6
Condition ...................................................................................... 78
Two kinds of data can be set in one model
Curve (EXP) ..................................................................................82
Steering operation curve/Throttle curve/Brake curve adjustment.
Steering curve ..........................................................................83
Throttle curve (Forward side) ...................................................84
Brake curve .............................................................................87
Speed ...........................................................................................88
Steering/Throttle servo delay adjustment
Steering speed .........................................................................88
Throttle speed ..........................................................................90
A.B.S. ............................................................................................94
Pulse brake
Traction Control ...........................................................................99
Function to make traction progress by intermittently moving the throttle
Start ............................................................................................103
Throttle preset at start function
Engine Cut .................................................................................105
Engine cut off by the switch
Steering Mixing ..........................................................................107
Twin servo steering system
Brake Mixing ..............................................................................110
Front and rear independent brake control for 1/5 GP car, etc.
Gyro Mixing ................................................................................114
Use to set the Futaba car rate gyro
4WS Mixing ................................................................................117
Special mixing used with Crawler and other 4WS type vehicles
Dual ESC ....................................................................................120
Front ESC and rear ESC
CPS Mixing .................................................................................122
Controls the Futaba CPS-1 channel power switch
Tank Mixing ................................................................................124
This function is intended for vehicles such as tanks
Program Mixing (1, 2, 3, 4, 5 ) ...................................................126
Programmable mixes between arbitrary channels
Tilt Mixing ...................................................................................129
Outboard engine
Timer ........................................................................................... 131
Up, Fuel down, lap, or lap navigation timer
Lap List .......................................................................................138
Lap timer data (lap time, average lap time) check
S.BUS Servo ...............................................................................139
The special function, Futaba S.BUS/S.BUS2 servo parameter/SR mode setup
MC (ESC) Link ............................................................................145
The special function, Futaba ESC (MC960CR, MC851C, MC602C, MC402CR...etc.)
Roll Out Chart ............................................................................154
Gear Ratio Chart ........................................................................155
HOME Button Setting ................................................................156

FUTABA 7PXR Specifications

General

Model	7PXR
Category	Remote Control
Channels	7
Frequency	2.4GHz
Telemetry	Yes
Model Memory	40
Display	Color LCD
Battery	6.6V
Compatibility	S-FHSS
Receiver	R334SBS
