FUTABA 7PXR User Manual

Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
* Throttle trigger position
* Throttle trigger position
* Throttle trigger position
91
Function
Speed
(Preparation)
-Tap the speed mode and select [1].
1
("ALL" turn direction delay adjustment)
Tap the [Turn] side of the [All] value button.
Value input buttons appear on the screen.
Use the [+] and [-] buttons to adjust the
turn speed amount.
(Preparation)
-Tap the speed mode and select [2].
1
("Low" and "High" turn direction delay adjustment)
Tap the [Turn] side of [Low] or [High] value
button. Value input buttons appear on the
screen. Use the [+] and [-] buttons to adjust
the turn speed amount.
Adjustment method for 1 Speed mode
Adjustment method for 2 Speed mode
2
("ALL" return direction delay adjustment)
Tap the [Return] side of the [All] value button. A warning is
displayed saying, "Return speed will be slow. Please be care-
ful.". If you want to use the return, tapped [Close]. Value input
buttons appear on the screen. Use the [+]
and [-] buttons to adjust the return speed
amount.
3
When finished, return to the Racing menu screen by pressing the HOME button twice.
1001
Servo operation is delayed.
1001
Servo operation is delayed.
1001
Servo operation is delayed.
Speed range
1~100
Initial value:
100, there is no delay.
Speed range
1~100
Initial value:
100, there is no delay.
Speed range
High: 1~100
Low: 1~100
Initial value:
100, there is no delay.
