2 Align the ball on the suction cup with the double-socket arm.
3 Tighten the knob slightly.
4 Remove the clear plastic from the suction cup.
5 Clean and dry your windshield and the suction cup with a lint-free cloth.
6 Press the suction cup to the windshield, and flip the lever back toward the windshield.
7 If necessary, rotate the Group Ride mount so the antenna faces up, adjust the mount for better viewing
and operation, and tighten the knob.
8 Fit the bottom of your device into the Group Ride mount.
9 Press the device into the Group Ride mount until it snaps into place.
10 Connect the Group Ride power cable to the connector on the automotive power cable .
11 Tighten the collar around the connected power cables.
12 Plug the other end of the automotive power cable into a power outlet in your vehicle.
148 Appendix
