NOTICE
Do not overtighten the +12V terminal to prevent damage to the terminal.
5 Connect the large ring end of the 12V cable to the positive terminal on the vehicle battery.
Title Pairing with a Garmin Navigation Device
Identifier GUID-28A16A38-DA54-4E53-B1E7-F481D59CC0D9
Language EN-US
Description
Version 2
Revision 3
Changes Changing ph_product_series and ph_smartphone_app_name for use in Tread
Status Released
Last Modified 25/11/2020 10:34:05
Author hizerdanielle
Pairing with a Garmin Navigation Device
You can pair your Garmin PowerSwitch device with a compatible Garmin navigation device.
1 Turn on power to your Garmin PowerSwitch device, and place your compatible Garmin navigation device
within 1 m (3.3 ft.) of it.
2 On your compatible navigation device, open the Garmin PowerSwitch app.
3 Follow the on-screen instructions to complete the pairing and setup process.
The main app dashboard appears. After the devices are paired, they connect automatically when they are turned
on and within range.
Title Specifications (Garmin PowerSwitch)
Identifier GUID-E9A53DAE-B84A-4E4F-9488-5536604B1779
Language EN-US
Description
Version 2
Revision 4
Changes Added power input details per SME feedback
Status Released
Last Modified 16/11/2020 15:30:23
Author mall
Garmin PowerSwitch Specifications
Dimensions (D x W x H) 75 x 125 x 32 mm (2.95 x 4.92 x 1.26 in.)
Operating temperature range From -25° to 85°C (from -13° to 185°F)
Wireless frequency 2.4 GHz @ 10 dBm
Power input From 12 to 16 V using the included vehicle power cable.
Maximum accessory output 30 A
Maximum system output 100 A
Current draw with all outputs off 3 mA
Water rating IEC 60529 IPX7
1
1
The device withstands incidental exposure to water of up to 1 m for up to 30 min. For more information, go to www.garmin.com/waterrating.
Appendix 157
