GE FVP110 - Mode Shedding on Computer Failure

121
Device Status
Resource Block
0x00008000 Servo output drift warning Shows the contents of the XD_ERROR in the
transducer block.
Refer to Table 36 on page 130 for details.
0x00004000 A/D Converter failure
0x00002000 Position sensor failure
0x00001000 Deviation error
0x00000800 Severe servo output drift
0x00000400 Pressure sensor failure
0x00000200 Temperature sensor failure
0x00000100 Deviation warning
0x00000080 Position sensor out of range
0x00000040 Pressure sensor out of range
0x00000020
Temperature sensor out of
range
0x00000010 Total near close limit exceed
0x00000008 Total close limit exceed
0x00000004 Total open limit exceed
0x00000002 Travel limit exceed
0x00000001 Cycle count limit exceed
Table 32 DEVICE_STATUS_3 (Continued)
Hexadecimal
Indication
Indication when
Device
Description is
Installed
Meaning
