IO_OPTS - Availability of Options
Function Block Parameters
IO_OPTS - Availability of Options for Each Block
STATUS_OPTS - Availability of Options for Each Block
Table 68 IO_OPTS - Availability of Options for Each Block
Bit Contents DI AO
0InvertX
1 SP tracks PV if Man X
2 Reserved
3 SP tracks PV if LO X
4 SP tracks RCas or Cas if LO or Man X
5 Increase to close X
6 Faultstate Type X
7 Faultstate Type X
8 Target to Man X
9 PV for BKCal_Out X
10 Reserved
Table 69 STATUS_OPTS - Availability of Options for Each Block
Bit Contents DI IS
(SIGSEL)
AO OS PID/PID2
0 IFS if BAD IN X
1 IFS if BAD CAS_IN X X
2 Use Uncertain as Good X X
3 Propagate Fault Forward X
4 Propagate Fault Backward X X
5 Target to Manual if BAD IN X
6 Uncertain if Limited
7 BAD if Limited
