Process Alarms
There are six types of process alarms (Table 53). Only one process alarm can be
generated at a time, and the process alarm having the highest priority level from among
those occurring at the same time is generated. The priority level is set for each process
alarm type.
Table 53 Process Alarms
Process Alarm Cause of Occurrence Parameter Containing
Priority Level Setting
HI_HI_ALM
Occurs when the PV increases above the
HI_HI_LIM value.
HI_HI_PRI
HI_ALM
Occurs when the PV increases above HI_LIM
value.
HI_PRI
LO_ALM
Occurs when the PV decreases below the
LO_LIM value.
LO_PRI
LO_LO_ALM
Occurs when the PV decreases below the
LO_LO_LIM value.
LO_LO_LIM
DV_HI_ALM
Occurs when the value of [PV - SP] increases
above the DV_HI_LIM value.
DV_HI_PRI
DV_LO_ALM
Occurs when the value of [PV - SP] decreases
below the DV_LO_LIM value.
DV_LO_PRI
