Alarm Processing
Block Alarms
When a condition shown in Table 44 is met in a DI block, the block changes the bit
statuses of BLOCK_ERROR accordingly and generates a block alarm.
Discrete Alarm
The parameter DISC_ALM is a discrete alarm of the parameter OUT_D.
When the value of OUT_D agrees with the value of DISC_LIM, the alarm state of
DISC_ALM is set to active and an alert is generated.
Table 44 BLOCK_ERROR in DI Block
Bit Meaning Description
3 Simulate Active SIMULATE_D is active.
7
Input Failure / process
variable has BAD status
Propagate Fault Backward in STATUS_OPTS is false, and the
sub-status component of the status of READBACK is sensor
failure or device failure.
15 Out of Service The target mode is O/S.
