FVP 110 Fieldbus Valve Positioner Manual
204
GE Energy
6 14006 BLOCK_ERR — — Indicates the error statuses related to the block
itself.
7 14007 SP Auto Indicates the setpoint for the block.
8 14008 OUT_1 O/S Indicates the value and status of output 1.
9 14009 OUT_2 O/S Indicates the value and status of output 2.
10 14010 OUT_1_RAN
GE
0-100% Defines the range of OUT_1 (output 1).
11 14011 OUT_2_RAN
GE
0-100% Defines the range of OUT_2 (output 2).
12 14012 GRANT_
DENY
0 Option to control access from the host
computer and local control panel to tuning and
alarm parameters.
13 14013 STATUS_OP
TS
0 O/S Defines block actions depending on block
status conditions.
14 14014 CAS_IN Cascade input.
15 14015 BKCAL_OUT Value returned to BLCAL_IN of the upstream
block; used by the upstream block to prevent
reset windup and perform bumpless transfer to
closed-loop control.
16 14016 IN_ARRAY (0, 0, 0, 0) O/S Settings used to convert SP to OUT_1.
17 14017 OUT_ARRAY (0, 0, 0, 0) O/S Settings used to convert SP to OUT_2.
18 14018 LOCKVAL 2 Defines the value of OUT_1 outside the set
endpoints of operation characteristic. 2 = Lock
19 14019 BKCAL_IN_1 Read-back value of OUT_1 returned from the
downstream block.
20 14020 BKCAL_IN_2 Read-back value of OUT_2 returned from the
downstream block.
21 14021 BAL_TIME 0 Defines the balancing time. After the cascade
connection to one downstream block has
already been established, the cascade
connection to the other downstream block will
be established over the time period defined by
this parameter.
22 14022 HYSTVAL 0 Defines the hysteresis for LOCKVAL. When it
is set to ‘No Lock.’
Table 64 OS Block Parameters (Continued)
Relative
Index
Index Parameter
Name
Default
(factory
setting)
Write Description
To Next Page
