GE MEDICAL SYSTEMS LOGIQ 400 SERVICE MANUAL
2127661
5–19 DIAGRAMS
REV 8
5–8 CIRCUIT BOARD DESCRIPTION (continued)
TABLE 5–1
CIRCUIT BOARD DESCRIPTION (continued)
.
ECG PANEL ASSY PIOP ASSY Physiological Signal Processor Assembly (1)
POWER SUPPLY
LV UNIT Low Voltage Unit 1
HV ASSY High Voltage Assembly 1
SPWR ASSY Subsidiary Power Assembly 1
PCONT ASSY Power Control Assembly 1
POWER SUPPLY
LV2 UNIT Low Voltage 2 Unit 1
HV UNIT High Voltage Unit 1
POWER SUPPLY
ASSY3
LV3 UNIT Low Voltage 3 Unit 1
TABLE 5–2
CIRCUIT BOARD VARIATIONS
BOARD NAME
VARIATIONS NOTE VERSION
TRDR ASSY TRDR ASSY
TRDR ASSY
2123305, used for console with software version 2.11 or former.
2123305–2, From console with software version 3.00.
Old TRDR Assy (2123305) can be replaced with new TRDR Assy
(2123305–2).
0
4 or 5
ASPR ASSY ASPR ASSY
ASPR ASSY
ASPR3 ASSY
ASPR3 ASSY
2123603, used foe console with software version 2.11 or former.
2123603–2, From console with software version 3.00.
Old ASPR Assy (2123603) can be replaced with new ASPR Assy
(2123603–2).
2192676, From console with software version 4.01 or later.
2192676–2, From console with software version 4.31.
Old ASPR3 Assy (2192676) can be replaced with new ASPR3 Assy
(2192676–2).
4
8, 9, or a
d
12
DOPC ASSY DOPC ASSY
DOPC ASSY
DOPC2 ASSY
DOPC3 ASSY
2123311–2, used for console with software version 2.11 or former.
2123311–3, From console with software version 3.00.
Old DOPC Assy (2123311–2) can be replaced with new DOPC Assy
(2123311–3).
2192564, From console with software version 4.01
2248949, From console with software version 4.31
1
4 or 5
8
c
TLMC ASSY TLMC ASSY
TLMC ASSY
TLMC ASSY
P9525WY, used for console with software version 2.11 or former.
2158390, From console with software version 3.00.
Old TLMC Assy (P9525WY) can be replaced with new TLMC Assy
(2158390).
2158390–2
Old TLMC Assy (P9525WY and 2158390) can be replaced with new
TLMC Assy (2158390–2).
2
4 or 5
8 or 9
