GE LOGIQ 400 - Rotation Spacer (FRU No. 206)

GE MEDICAL SYSTEMS LOGIQ 400 SERVICE MANUAL

2127661
RENEWAL PARTS
6–124
REV 9
6–2–30 Rotation Spacer (FRU No. 206)
Note
The Rotation Spacer is used only for the B/W monitor console.
Time Required
0.5 Hours
Tool Required
Screwdriver
Hexagonal Wrench
Procedure
WARNING!
PERSONAL INJURY HAZARD. THE NECK ASSY IS SPRING LOADED. RELEASING ARM
WHEN MONITOR IS NOT INSTALLED WILL CAUSE SUDDEN UPWARD MOVEMENT. KEEP
YOUR HEAD AND BODY AWAY FROM ABOVE NECK ASSY.
Refer to ILLUSTRATION 6–52 on page 6–125.
1. Turn OFF the system.
2. Remove the Monitor Assy NTSC (FRU No. 150) or Monitor Assy PAL (FRU No. 151). Refer to 6–2–12 on page
6–90.
3. Unscrew one screw (
1
).
4. Remove the Rotation Spacer.
