GE LOGIQ 400 Service Manual

2127661
LOGIQ 400 SERVICE MANUALGE MEDICAL SYSTEMS

RENEWAL PARTS
6–230
REV 9
6–2–93 HV Unit (FRU No. 750)
Time Required
30 Minutes
Tool Required
Screwdriver
Procedure
Refer to ILLUSTRATION 6–128 on page 6–231.
1. Turn OFF the system and unplug the main power cord.
2. Remove the Front Base Cover (FRU 305). Refer to 6–2–35 on page 6–131.
3. Remove the Side Cover Right (FRU 302). Refer to 6–2–32 on page 6–128.
4. Unscrew four screws (
1
–
4
).
5. Remove the RIGHT PS COVER.
6. Unscrew three screws (
5
–
7
).
7. Disconnect one flat cable (
8
) from the PCONT ASSY on the HV Unit.
8. Pull the HV Unit outwards.
9. Disconnect eight (8) connectors (
9
–
16
) out of the HV Unit.
10. Remove the HV Unit (FRU 750).
