GE MEDICAL SYSTEMS LOGIQ 400 SERVICE MANUAL
2127661
RENEWAL PARTS
6–72
REV 9
6–2–2 Monitor Cover Set (FRU No. 101)
Time Required
20 Minutes
Tool Required
Screwdriver
Procedure
Refer to ILLUSTRATION 6–15 on page 6–73.
1. Turn OFF the system.
2. Unscrew three screws (
1
–
3
).
3. Remove the Monitor Cover L Assy (FRU 104).
4. Unscrew three screws (
4
–
6
).
5. Remove the Monitor Cover R Assy (FRU 105).
6. Remove the Monitor Cover Top Assy (FRU 106).
7. Push and open the Escutcheon Front Door (FRU 107).
8. Pull the two caps (
7
, FRU 108: CRT Cap Set) out.
9. Loosen four screws (
8
–
11
).
10. Disconnect one connector of task lamp switch.
11. Remove the Escutcheon Assy (FRU 102).
Note
Monitor Cover Set (FRU 101) includes the Escutcheon Assy (FRU 102), Escutcheon Latch (FRU
103), Monitor Cover L Assy (FRU 104), Monitor Cover R Assy (FRU 105), Monitor Cover Top Assy
(FRU 106), and the Escutcheon Front Door (FRU 107).
Note
When replacing the Escutcheon with the new Monitor Cover Set (2162082) or replacing the Escutch-
eon Assy (2162083), be sure to attach the proper label on the Escutcheon. To attach the new label,
refer to the procedures described in the following pages.
Note
The color of the Escutcheon for the LOGIQ 400CL is different from the other color monitor assy. Use
the proper FRU when replacing the monitor cover set for the LOGIQ 400CL.
To Next Page
