GE MEDICAL SYSTEMS LOGIQ 400 SERVICE MANUAL
2127661
RENEWAL PARTS
6–94
REV 9
6–2–14 Escutcheon Assy (FRU No. 153) (continued)
Note
The new Escutcheon Assy (2164507) includes the two different labels for the Escutcheon. When re-
placing the Escutcheon with the new Escutcheon Assy, be sure to attach the proper label on to the
Escutcheon as follows:
a. Choose the proper label, “LOGIQ 400” or “LOGIQ 400 MD” indicating the same model name as the label on
the removed Escutcheon.
b. Remove the lower pasteboard from the proper label. Refer to ILLUSTRATION 6–31.
REMOVING LOWER PASTEBOARD
ILLUSTRATION 6–31
c. Set and attach the label on the Escutcheon. Adjust the position of the label attached as shown in
ILLUSTRATION 6–32. Be careful not to attach the label with a misalignment.
ATTACHING LABEL
ILLUSTRATION 6–32
To Next Page
