GE MEDICAL SYSTEMS
2127661
LOGIQ 400 SERVICE MANUAL
FUNCTIONAL CHECKS
4–35
REV 6
4–3–3 Utility Menu (continued)
(L) NETWORK ERROR LOG DISPLAY
This displays and copies an error log file into a MO disk.
Note
This function is available only when the optional Storage/Print DICOM is enabled on the console with
the system software version 3.40 or later.
Type 11 (12 on the console with the software V4.01 or later) and then press Return key when the Utility Menu is
displayed. The Network Error Log Display menu is displayed as shown in ILLUSTRATION 4–27.
NETWORK ERROR LOG DISPLAY
ILLUSTRATION 4–27
Procedure for Saving File
1. Type Y and then press Return key.
2. Insert a MO disk into the MOD drive and press any key.
During the time that the system is copying the error log file, “Copying now” is displayed on the CRT monitor
screen.
To Next Page
