GE MAC 1600

9-20 MAC™ 1600 2028451-182B
System Configuration
Export XML Determines whether ECG records will be transmitted as
XML. If set, ECG records exported to SD card will be
stored in both XML and Hilltop formats. If not set, ECG
records exported to SD card will be stored only in Hilltop
Serial Baud Rate Determines the speed at which data will be transmitted
across the serial communications port.
Allow Export Using Shared
Directory
Determines whether ECG records can be exported to a
shared network drive. Available only if the LAN
Communications to CardioSoft option (LANC) has been
activated.
If this field is checked, the following five fields become
available.
Share Name Identifies the name of the shared network drive. It must be
the share’s name; IP addresses are not supported.
Maximum of 256 characters.
Available only if the Allow Export Using Shared Directory
field is checked.
Username Identifies the user name that the MAC 1600 system will
use to log on to the shared directory. The user must be set
up on the domain with the appropriate permissions to
access the shared directory. Maximum of 30 characters.
Available only if the Allow Export Using Shared Directory
field is checked.
Password Identifies the password that the MAC 1600 system will use
to log on to the shared directory. Maximum of 30
characters.
Available only if the Allow Export Using Shared Directory
field is checked.
Confirm Re-enter the password in this field to confirm that the
password was typed correctly.
Available only if the Allow Export Using Shared Directory
field is checked.
Domain Identifies the user’s domain. Maximum of 30 characters.
Available only if the Allow Export Using Shared Directory
field is checked.
Page 2
Location Identifies the name of a communication location that will
receive the transmission from the MAC 1600 system. Up to
four locations can be defined.
Field Comment
