9-6 MAC™ 1600 2028451-182B
System Configuration
Resting ECG Setup
The Resting ECG Setup option allows you to define:
Waveform parameters
Lead usage
Analysis options
Lead sequence
Report options
Storage options (if the internal storage option is activated)
Transmission options (if a communications option is activated)
To reach the Resting ECG Setup from the MAC 1600 Main Menu, press
F5 (System Configuration) > F2 (Resting ECG Setup).
The following table describes each setting available on the Resting ECG
Setup.
Field Comment
Page 1
Gain [mm/mV] Sets the amplitude of the ECG signal. Measurement is in
millimeter per millivolt and includes the following options.
2.5
5
10
20
40
Automatic
The larger the selected measurement, the larger the
waveform. Only the appearance of the waveform changes;
signal strength is not affected.
NOTE
If Automatic is selected, the system calculates the
best gain based on the peak-to-peak amplitudes of all
displayed leads and the selected display format.
Speed [mm/s] Changes the speed of rhythm printing and that the wiper
bar moves across the display.
Measurement is in millimeter per second (mm/s) and
includes the following options.
5 (rhythm) / 12.5 (display)
12.5
25
50
