GE MAC 1600

Arrhythmia Mode Recording
2028451-182B MAC™ 1600 6-5
Printing Options
When printing an arrhythmia report, you have the following options.
Arrhythmia Codes
The following table identifies the codes used on the arrhythmia reports
and the events they represent.
F1 Pace Enhance Improves the readability of pacemaker ECGs. Options
are On and Off.
F3 Patient Data Opens the patient data entry window.
F5 Main Menu Exits the Arrhythmia function and returns to the Main
Menu.
F Key Option Description
F Key Option Description
F1 Print Summary Prints a combined report that includes both the Table
and Episode formats.
F2 Print Table Prints a breakdown of the recording in tabular format.
The report includes:
 the analysis duration in minutes and seconds,
 the artifact duration in minutes and seconds,
 a code for each event type recorded, and
 the number of each event type recorded.
For a description of the possible event codes, refer to
“Arrhythmia Codes” on page 6-5.
F3 Print Episodes Prints a standard waveform report of the recorded
events. The signal from all recorded leads is printed,
and each event is marked with the corresponding
arrhythmia code.
For a description of the possible event codes, refer to
“Arrhythmia Codes” on page 6-5
Code Arrhythmia Event
AArtifact
ASYSTO Asystole, limit value 3 s
CPLT Ventricular couplet (2 PVCs)
ESC Ventricular escape beat
