GE MAC 1600

9-12 MAC™ 1600 2028451-182B
System Configuration
Arrhythmia Setup
The Arrhythmia Setup function allows you to define:
 Waveform parameters
 Lead usage
 Analysis options
 Lead sequence
 Report options
To reach the Arrhythmia Setup from the MAC 1600 Main Menu, press
F5 (System Configuration) > F3 (Arrhythmia Setup).
Most of the fields on the Arrhythmia Setup windows are the same as
those on the Resting ECG Setup. The following table lists the arrhythmia
settings that are unique or differ from the resting ECG. For all other
fields, refer to “Resting ECG Setup” on page 9-6.
Delete after Transmission Determines whether the ECG will be deleted from internal
storage after it is transmitted to an external device.
Available only if one of the communications options is
activated.
For more information, refer to “Options Setup” on
page 9-29.
Print Transmission Log Determines whether the transmission log prints after an
ECG is transmitted from File Manager to an external
device. Available only if one of the communications options
is activated.
For more information, refer to “Options Setup” on
page 9-29.
Field Comment
Field Comment
Page 1
ADS Enables/disables the Anti-Drift System, which helps reduce
baseline shift. In Arrhythmia mode, this setting is always
available.
Page 2
Rhythm Printing Determines whether the rhythm report will start
automatically when recording starts.
