Equipment Overview
2028451-182B MAC™ 1600 2-7
Leadwire Adapters
The leadwires require an adapter to connect to an electrode, as shown in
the following illustration.
010
Setting Up the Equipment
Setting up the MAC 1600 system consists of the following steps:
1. Inserting the battery.
2. Connecting the AC power adapter.
3. Connecting leadwires.
4. Inserting paper.
Name Description
A D-Sub 15-pin male
connector
Connects to the system’s ECG signal input connector.
One end of each acquisition cable consists of a D-sub
15-pin male connector.
B Multi-link Acquisition
Cable Leads
The lead end of the multi-link acquisition cable
attaches to the leadwire adapters and uses 10 or 12
leadwires.
C NEHB Acquisition
Cable Leads
The lead end of the NEHB acquisition cable attaches to
the leadwire adapters and uses 12 leadwires.
D Value Acquisition Cable
Leads
The lead end of the value acquisition cable consists of
10 leadwires.
A leadwire end
B 4 mm pin
C grabber
D Mactrode clip
