5-2 MAC™ 1600 2028451-182B
Recording a Resting ECG
Introduction
The Resting ECG function is part of the basic MAC 1600 system. Resting
ECG mode is the default Power up mode. When the system is turned on,
the Resting ECG display will appear, similar to the following figure. The
default can be modified in the Basic Setup.
045A
Resting ECG Display
Item Name Description
A ECG Type Type of ECG. Valid types are Resting ECG,
Arrhythmia, and Stress Test.
B Display Format Format of current waveforms. Press the Leads key
to cycle through all 12 leads.
C Date Current system date.
D Time Current system time.
E Battery status indicator Displays the current battery level.
F Internal storage indicator Appears only if the internal storage option is
enabled. Format: Approximate number of ECG
records that can be stored in remaining memory /
Maximum number of ECG records that can be
stored.
G Hookup Advisor Indicator See “Hookup Advisor Module” on page 5-12 for
more information.
