System Configuration
2028451-182B MAC™ 1600 9-7
Low Pass Filter [Hz] Sets the maximum frequency to include in the waveform.
Restricting frequencies can help eliminate noise in the
waveform. Frequencies are measured in Hertz (Hz) and
include the following options.
20
40
100
150
Selecting a frequency eliminates signals above that
frequency. For example, if you select 40, only signals that
have a frequency of 40 Hz or lower are included in the
waveform.
High Pass Filter [Hz] Sets the minimum frequency to include in the waveform.
Restricting frequencies can help eliminate noise in the
waveform. Frequencies are measured in Hertz (Hz) and
include the following options.
0.04
0.08
0.16
0.31
Selecting a frequency eliminates signals that fall below that
frequency. For example, if you select 0.16, only signals
that have a frequency of 0.16 Hz or higher are included in
the waveform.
ADS Enables/disables the Anti-Drift System, which helps reduce
baseline shift. In Resting ECG mode, this field is available
only if the MEHR or MIHR option is enabled. For more
information on enabling options, refer to “Options Setup”
on page 9-29.
Line Filter Enables/disables the line filter defined in Country Setup.
Refer to “Country Setup” on page 9-23 for more
information.
6 leads: 1x6 Enables/disables a display option that shows one six-
waveform column.
6 leads: 2x3 Enables/disables a display option that shows two three-
waveform columns.
12 leads: 2x6 Enables/disables a display option that shows two six-
waveform columns. Available only if the R12L system
option is enabled.
Field Comment
To Next Page
