CHAPTER 8: USING THE D400
D400 SUBSTATION GATEWAY INSTRUCTION MANUAL GE INFORMATION 111
System status points
You can obtain status information about your D400 through several system points. These
points can be viewed through the Application tab on the Point Summary window.
Table 26: D400 System Status Points
FPGA Version 1.10 or above is required to provide system status points for the power
supplies and 100BASE-FX card. In previous FPGA versions, these points appear as offline
regardless of their actual status. If your FPGA version is 1.09 or less, please contact Product
Support.
Name Data Type Description
Power Supply 1 Good Digital Input Value is 1 when a failure has occurred or the power
supply is not installed. Because this point remains
online even when the power supply is not installed, you
can force the point for the missing supply to the offline
state or you can apply a tag indicating that the unit is
not installed.
Power Supply 2 Good Digital Input
IRIG-B Enabled Digital Input Value is 1 when enabled
IRIG-B Watchdog Expired Digital Input Value is 1 when expired
Front Port Link Good Digital Input Value is 1 when true
Note that “Active” is not the same as “Activity”. It is used
in the same sense as Active and Standby for redundant
Ethernet configurations. The point does not flicker on
and off in the same way that the activity LED does for
an Ethernet port.
The actual number of ports available depend on the
configured options of the
D400 unit. Points associated
with unavailable ports are made offline and invalid.
NET1 Port 1 Link Good Digital Input
NET1 Port 1 Active Digital Input
NET1 Port 2 Link Good Digital Input
NET1 Port 2 Active Digital Input
NET1 Port 3 Link Good Digital Input
NET1 Port 3 Active Digital Input
NET1 Port 4 Link Good Digital Input
NET1 Port 4 Active Digital Input
NET2 Port 1 Link Good Digital Input
NET2 Port 1 Active Digital Input
NET2 Port 2 Link Good Digital Input
NET2 Port 2 Active Digital Input
NET2 Port 3 Link Good Digital Input
NET2 Port 3 Active Digital Input
NET2 Port 4 Link Good Digital Input
NET2 Port 4 Active Digital Input
System PLD Revision Analog Input A string that describes the revision or ID number of the
specified component.
Main Board ID Analog Input
Mid-Plane ID Analog Input
NET1 Card ID Analog Input
NET2 Card ID Analog Input
USB KVM Card ID Analog Input
