CHAPTER 13: SERVICING THE D400
D400 SUBSTATION GATEWAY INSTRUCTION MANUAL GE INFORMATION 163
Dual ethernet upgrade kit with card 580-3410
The D400 Dual Ethernet Upgrade Kit allows you to upgrade your existing D400 device to
support dual Ethernet network connections. This upgrade kit contains the following
components:
• PC/104-PLUS 10/100/1000BASE-TX Dual Ethernet card (GE part number 580-3410)
• Ethernet card to main board cable assemblies (GE part numbers 977-0544 and 977-
0549)
• Phillips screws (4 pieces)
• Hexagonal standoffs (4 pieces)
• Hexagonal nuts (4 pieces)
Valid combinations
This upgrade can be performed using the following components:
Perform this procedure on an ESD-safe surface to prevent damage to the D400 device and
its components.
Installing the 580-3410 dual ethernet card
The 580-3410 dual ethernet card only works in conjunction with the 1.0 GHz or 1.6 GHz
CPU.
To install the Dual Ethernet Upgrade Kit:
1. Power down your D400 device.
2. Remove the D400 main module from the chassis. See “Removing the D400 main
module” on page 159.
3. Locate the four mounting holes in the D400 main module PCB board noted below.
Attach the hexagonal standoffs to the top of the main board and secure the standoffs
using the four provided hexagonal nuts.
D400 Main Board Ethernet Module Card Network Cards
GE part # 520-0205LF [1.0 GHz]
GE part # 520-0232LF [1.6 GHz]
GE part # 580-3410 GE part # 520-0218LF [NET1 slot]
GE part # 520-0213LF [NET2 slot]
GE part # 520-0214LF [NET2 slot]
GE part # 520-0215LF [NET2 slot]
GE part # 520-0218LF [NET2 slot]*
* This configuration is only
supported with firmware v5.01
configured for PRP.
