APPENDIX B: INSTALLING AND CONNECTING DNP3 I/O MODULES
D400 SUBSTATION GATEWAY INSTRUCTION MANUAL GE INFORMATION 179
DNP3 I/O module (LV) connection to the Power Source
Connect the power supply to the last DNP3 I/O module in the chain.
The cable from J2 on the last DNP3 I/O module to the power source (GE part number 977-
0500) provides the connections shown in the wiring diagram of
Figure 71.
Figure 71: Power cable 977-0500 wiring diagram
1
2
3
4
5
6
7
9
8
Not Connected
+
DC
-DC
+ V
-V
Not Connected
Power Supply
DB
9
Male
