Chapter 8 - Replacement Procedures 8-99
D
IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
PRELIMINARY
8-6-7-5 Plastic Cable Guide for CFE Installation Procedure
1.) Install the new Plastic Cable Guide for CFE and slightly tighten the two screws to secure the cable
guide in its place.
2.) Reconnect the BIB cable to the Plastic Cable Guide for CFE.
3.) Return the FE door support to its place.
4) Close the FE door and close the two fastening latches on the left side of the Front End door
assembly.
5.) Tighten the captive screw.
6.) Refit the following covers: Lower Front eTower, left side eTower, Right side eTower and RS Probe
cover.
7.) Install all accessories.
8.) Turn ON power to the system.
• Left Side eTower Cover Installation Procedure
• Right Side eTower Cover Installation Procedure
• Lower Front eTower Cover Installation Procedure
• RS Probe Cover Installation Procedure
• Accessories - Replacement Procedures
Perform the checks listed in Plastic Cable Guide for CFE Replacement Procedure on page 8-218
