gefran SIEIDrive ADV100 User Manual

34 ADV100 • Functions description and parameters list
8 Output & ref = low lim
9 Input = upp lim
10 Input & ref = upp lim
11 Freeze input
When set to None, no setting is executed.
Input=0 sets input = 0 i.e. a temporary reference setting is performed and the previous reference value is main-
tained. The output of the Motor potentiometer function varies with the set ramp times. The previous reference value
is restored when the preset command is removed.
Input=lowlim sets Inp = low lim i.e. a temporary reference setting is performed and the previous reference value
is maintained. The output of the Motor potentiometer function varies with the set ramp times. The previous reference
value is restored when the preset command is removed.
Input&ref=0 sets Inp = 0 and Ref = 0 i.e. a denitive reference setting is performed. The output of the Motor po-
tentiometer function varies with the set ramp times.
Input&ref=lowlim sets Inp = low lim and Ref = low lim i.e. a denitive reference setting is performed. The output
of the Motor potentiometer function varies with the set ramp times.
Output=0 sets Out = 0 i.e. a temporary output setting for the Motor potentiometer function is performed. The previ-
ous reference value is maintained. If the preset command is enabled, the output of the Motor potentiometer function
continues to be = 0, if the preset command is not enabled the output of the Motor potentiometer function varies with
the set ramp times.
Output=lowlim sets Out = low lim i.e. a temporary setting for the output of the Motor potentiometer function is
performed. Il precedente valore di riferimento viene mantenuto .The previous reference value is maintained. If the
preset command is enabled, the output of the Motor potentiometer function continues to be = low lim, if the preset
command is not enabled the output of the Motor potentiometer function varies with the set ramp times.
Output&ref=0 sets Out = 0 i.e. a denitive setting for the output of the Motor potentiometer function is performed.
Output&ref=low lim sets Out = low lim i.e. a denitive setting for the output of the Motor potentiometer function is
performed.
Input=upplim sets Inp = upp lim i.e. a temporary setting for the reference is performed and the previous reference
value is maintained. The output of the Motor potentiometer function varies with the set ramp times. The previous
reference value is restored when the preset command is removed.
Input&ref=upplim sets Inp = upp lim and Ref = upp lim i.e. a denitive reference setting is performed. The output
of the Motor potentiometer function varies with the set ramp times.
When Freezeinput is set, the Up and Down commands are temporarily disabled.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
8.8 884 Mpotupsrc LINK 16 6000 0 16384 RW FVS
Selection of the origin (source) of the signal that increases the speed reference of the motor potentiometer with the
set ramp. The terminal to be associated with this function can be selected from the “L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
8.9 886 Mpotdownsrc LINK 16 6000 0 16384 RW FVS
Selection of the origin (source) of the signal that decreases the speed reference of the motor potentiometer with the
set ramp. The terminal to be associated with this function can be selected from the “L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
8.10 888 Mpotinvertsrc LINK 16 6000 0 16384 ERW FVS
Selection of the origin (source) of the signal that inverts the speed reference of the motor potentiometer. The termi-
nal to be associated with this function can be selected from the “L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
8.11 890 Mpotpresetsrc LINK 16 6000 0 16384 ERW FVS
