ADV100 • Functions description and parameters list 45
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.3 1004 Enable/disablemode ENUM Stop/FS&Spd=0 0 3 ERW FVS
This parameter is used to dene the generation of Enablecmdmon, i.e. to congure the type of control used for
enabling and disabling the drive.
0 Off
1 Stop/FS&Spd = 0
2 Stop&Spd = 0
3 FS&Spd = 0
If set to 0Off:
In Terminal mode the drive is enabled and disabled via the Enable terminal.
In Digital mode the drive is enabled and disabled when the signal on the Enable terminal and the DigitalEnable
command are present simultaneously.
In Keypad mode the drive is enabled if the hardware is enabled on the Enable terminal and the Start key is
pressed.
In Keypad mode it is disabled if the hardware is not enabled on the Enable terminal or if the Stop key is pressed
twice.
If 1Stop/FS&Spd=0 is set:
In Terminal mode the drive is enabled when the hardware is enabled on the Enable terminal, on the terminal pro-
grammed as TerminalStart and the FastStop terminal must not be enabled.
In Terminal mode the drive is instantly disabled if there is no signal on the Enable terminal, or when speed=0 is
reached if the Startcommand is disabled or the terminal programmed as FastStop is enabled.
In Digital mode the drive is enabled when the hardware is enabled on the Enable terminal, the DigitalEnable, In
Digital mode the drive is instantly disabled if there is no signal on the Enable terminal, or when speed=0 is reached
if the DigitalStart command is disabled or the terminal programmed as FastStop is enabled.
In Keypad mode the drive is enabled if the hardware is enabled on the Enable terminal and the Start key is
pressed, with the command disabled on the FastStop terminal.
In Keypad mode the drive is disabled instantly if the signal is not present on the Enable terminal or the Stop key is
pressed twice.
If 2Stop&Spd=0is set:
In Terminal mode the drive is enabled if the hardware is enabled on the Enable terminal and the signal is enabled
on the terminal programmed as TerminalStart.
In Terminal mode the drive is instantly disabled if there is no signal on the Enable terminal, or if, upon reaching the
speed=0, the TerminalStart command is disabled.
In Digital mode the drive is enabled when the hardware is enabled on the Enable terminal and the DigitalEnable
and DigitalStart signals are present.
In Digital mode the drive is instantly disabled if the signal is not present on the Enable terminal, or the DigitalEn-
able command is not present, or upon reaching the speed=0 if the DigitalStart command is set to 0.
In Keypad mode the drive is enabled when the hardware is enabled on the Enable terminal and the Start key is
pressed.
In Keypad mode the drive is instantly disabled if the signal is not present on the Enable terminal or the Stop key is
pressed twice, or when the speed=0 is reached if the Stop key is pressed.
If 3FS&Spd=0 is set:
In Terminal mode the drive is enabled when the hardware is enabled on the Enable terminal and the FastStop
terminal is not enabled.
In Terminal mode the drive is instantly disabled if there is no signal on the Enable terminal, or when the speed=0 is
reached if the terminal programmed as FastStopis enabled.
In Digital mode the drive is enabled if the hardware is enabled on the Enable terminal and the DigitalEnable signal
is present, with the command on the FastStop terminal disabled.
In Digital mode the drive is instantly disabled if there is no signal on the Enable terminal, or no DigitalEnable com-
mand, or when the speed=0 is reached if the DigitalStart command is set to 0.
