46 ADV100 • Functions description and parameters list
In Keypad mode the drive is enabled if the hardware is enabled on the Enable terminal and the Startkey is
pressed, with the FastStop command disabled.
In Keypad mode the drive is instantly disabled if there is no signal on the Enable terminal or the Stop key is pressed
twice, or if, when the speed=0 is reached, the terminal programmed as FastStop is enabled.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.4 1006 Speed0disabledly ms UINT16 1000 0 10000 ERW FVS
Setting of a delay in milliseconds between reaching the zero speed and disabling the drive when Enable/Disable
mode is set to a value other than Off.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.5 1008 Stopkeymode ENUM Inactive 0 1 ERW FVS
Setting of the stop key functioning on the keypad in case of Remote->Terminal or Remote->Digital or Local-
>Terminal mode. In Local -> Keypad mode this conguration is ineffective.
0 Inactive
1 EmgStop&Alarm
If the command is set to Inactive, pressing the Stop key on the keypad is ineffective.
If the command is set to EmgStop&Alarm, when the Stop key is pressed the motor stops in FastStop mode and the
Emgstopalarm is generated. When the motor reaches the speed=0, the drive is automatically disabled and waits
for the Faultreset command. The Faultreset command must be sent twice to reset the drive.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.6 1010 Commandssafestart BIT 1 0 1 ERW FVS
This parameter is used to dene whether the safe start command is disabled or enabled at drive power-on.
0 Off
1 On
If set to Off, the safe start command is disabled. If the drive is powered-on with the hardware enabled on the Enable
terminal, the motor could start rotating.
When set to On, the safe start command is enabled. If the drive is powered-on with the hardware enabled on the
Enable terminal, the motor will not rotate. To set the drive to accept subsequent commands, open the hardware
enabling contact on the Enable terminal and then close it again.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.7 1012 Diglocal/remote ENUM 16 Remote 0 1 ERW FVS
Setting Local or Remote operating mode.
0 Local
1 Remote
Writing this parameter is only effective if it is associated with Local/Remotesrc and if performed without the hard-
ware enabled on the Enable terminal. Press LOC to modify the value of this parameter 0<->1.
To disable the LOC key, set Local/Remotesrc to a value other than Diglocal/remote.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.8 1014 Local/remotesrc LINK 16 1012 0 16384 ERW FVS
Selection of the origin (source) of the signal that switches between Remote and Local. Switching can only be per-
formed if the hardware is not enabled on the Enable terminal.
The signal to be associated with this function can be selected from the “L_DIGSEL3” selection list.
