ADV100 Functions description and parameters list 47
0 Local
1 Remote
In Remote mode the “Commandsremotesel” parameter is used to congure the source of the Enable and Start
commands, which can be Terminal (standard digital input, expansion digital input) or Digital (Modbus, Fieldbus,
Prole DS402, Prole prodrive).
In Local mode the “Commandslocalsel” parameter is used to congure the source of the Enable and Start com-
mands, which can be Terminal (standard digital input, expansion digital input) or Keypad (Start key, Stop key).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.9 1016 TerminalStartsrc LINK 16 1048 0 16384 ERW FVS
Selection of the origin (source) of the TerminalStart signal. Switching can only be performed if the hardware is not
enabled on the Enable terminal.
The signal to be associated with this function can be selected from the “L_DIGSEL3” selection list.
In the default condition, the origin of the Terminal Start signal is the Start output of the ForwardReverseControl
(FRC) block.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.10 1018 DigitalEnablesrc LINK 16 6000 0 16384 ERW FVS
Selection of the origin (source) of the signal that denes the enabling of the drive when the commands are sent via
serial line or eldbus. The command to be associated with this function can be selected from the “L_DIGSEL2
selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.11 1020 DigitalStartsrc LINK 16 6000 0 16384 ERW FVS
Selection of the origin (source) of the Digital Start signal. The signal to be associated with this function can be se-
lected from the “L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.12 1022 FastStopsrc LINK 16 6000 0 16384 ERW FVS
Selection of the origin (source) for the fast stop signal (FastStop). The terminal to be associated with this function
can be selected from the “L_DIGSEL2” selection list. During the execution of the FastStop command the ramps
used are Accelerationtime3 and Decelerationtime3.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.13 1024 Enablecmdmon BIT 16 0 0 1 R FVS
The status of the enable command is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.14 1026 Startcmdmon BIT 16 0 0 1 R FVS
The status of the Start command is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.15 1028 FastStopcmdmon BIT 16 0 0 1 R FVS
The status of the FastStop command is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.16 1040 FRmode ENUM Normal 0 2 ERWZ FVS
Setting of the operating mode of the Forward Reverse Control (FRC) block.
0 Normal
1 Two wire Two wire control
