ADV100 • Functions description and parameters list 57
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
14.14 1628 Aninp1Xaltselsrc LINK 16 6000 0 16384 ERW FVS
14.29 1678 Aninp2Xaltselsrc LINK 16 6000 0 16384 ERW FVS
Selection of the origin (source) of the signal to be assigned to the relative digital input for selecting the alternative
analog reference. The functions that can be associated with the digital outputs are listed in the “L_DIGSEL2” selec-
tion list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
14.15 1632 Analoginp1Xdest ILINK 0 0 0 ER FVS
14.30 1682 Analoginp2Xdest ILINK 0 0 0 ER FVS
The function for which the relative analog input of the expansion card has been programmed and on which it acts is
displayed.
