3•18 Reference Guide
○○○○○○○○○○○○○○○○○○○○○○
3•18 Reference Guide
THE SWITCH PEDAL FUNCTIONS
Off No effect
Damper Applies the sustain effect to released
notes.
Sostenuto Sustains only the notes played at the
time of pressing the pedal; notes
played after pressing the pedal are
not affected.
Soft Attenuates the sound.
Start/Stop Simulates the Start/Stop button.
Key Start Activates/deactivates the Key Start
function.
Intro Activates the Intro.
Fill < Activates the Fill< function.
Fill = Actvates the Fill function.
Fill > Activates the Fill> function.
Ending Activates the Ending function.
Variation 1 Switches to Variation 1.
Variation 2 Switches to Variation 2.
Variation 3 Switches to Variation 3.
Variation 4 Switches to Variation 4.
Var > Switches to the next Variation.
Var < Switches to the previous Variation.
Prst > Advances to the next Preset.
N.B. To select Presets sequentially
in increasing order, all those you
want to recall should be pro-
grammed for the action of the Prst>
function.
Prst < Returns to the previous Preset.
N.B. To select Presets sequentially
in decreasing order, all those you
want to recall must be programmed
for the action of the Prst< function.
Harmony Activates/deactivates the Harmony
On/Off button.
Bass to Low. Activates/deactivate the Bass to
Lowest function.
Arrange On/Off Activates/deactivates the Arrange
On/Off button.
Fade In/Out Activates/deactivates the Fade In/
Out function.
Tempo > Increases the Tempo setting by one
unit at a time.
Tempo < Decreases the Tempo setting by one
unit at a time.
Punch Activates/deactivates the Punch re-
cording function during recording
operations.
Rotary s/f Changes the speed of the Rotary
effect from Slow to Fast or vice versa.
Minor Converts the currently held chord to
the minor chord.
Dim Converts the currently held chord to
the diminished chord.
Min 7th Converts the currently held chord to
the minor 7th chord.
Maj 7th Converts the currently held chord to
the Major 7th chord.
Hardcopy Captures a Bitmap image of the cur-
rent Display.
Vocal On/Off Activates/deactivates the Vocal Proc-
essor for Vocal harmonies.
Vocal Custom 1-16 Recalls custom Vocal Processor
Voice settings.
Vocal Mute Mutes the Vocal Track when using
the Vocal harmonies.
Vocal Chord/Vocoder/Unison Switches from one Vo-
cal Processor operating mode to the
other.
Freeze Chord ‘Locks’ the current chord (pedal
held), allowing you to play freely with
both hands across the entire key-
board without triggering changes in
the Style auto-accompaniment. The
function deactivates at pedal release.
