Disk 4•7
○○○○○○○○○○○○○○○○○○○○○○
Disk 4•7
In the dispay example of the previous page,
the disk directory shows the presence of one
Percussive Sample (GRV.bpm 106) with Pr.
Change and Bank Select number 114-6.
4. Select (if necessary) the Sample and its
corresponding destination in RAM (114-6).
Use the +/– Page/Bank buttons to scroll the
Sound Groups (1, 2, … 15, 16). In this case,
scroll to Group 15 (Percussive - example A).
Use the directional arrows to scroll to the
desired Bank (in this case, bank 6) and des-
tination (Program Change 114 - example B).
5. Press ENTER twice to load the Sample file to
memory.
Note: It is recommended to load Sounds and Sam-
ples to their original locations to facilitate the on-board
file search facilities, but you are free to load them to
any Group.
LOAD GROUP
The Load Group command offers a quick way of
loading a Groups of 8 elements at a time.
Warning: The Group currently in memory is
overwritten by the incoming Group. If, for example,
the User Style Group you are loading contains only
one User Style, all User Styles of the destination
Group currently in RAM will be cancelled and replaced
by the new Group. Be sure that your Group data are
safely saved to Disk or Hard Disk before proceeding.
Load Group offers the following possibilities:
LOAD GROUP GLOBAL PRESET
Loads a Group of up to 8 user-programmed Glo-
bal Presets to any Global Preset Group destina-
tion.
LOAD GROUP USER STYLE
Loads a Group of up to 8 User Styles (and corre-
sponding Presets) to any User Group destina-
tion.
LOAD GROUP SONG
Loads Songs as “virtual Groups” (Song Group 1
and Song Group 2 found in the Disk environment
only). Each virtual group corresponds to the first
8 or second 8 locations of the Song memory. In
fact, in normal conditions when you press the
Song button to select a Song, the song selection
display shows two columns, left and right. The
left column corresponds to the virtual Songs-
Group 1 and the right to Songs-Group 2. This
feature is particularly useful for the WX Series
Songs disks which contain Song Groups contain-
ing up to 8 Songs each.
LOAD GROUP STYLE PRESET
Loads a Group of 8 Style Preset banks, each bank
containing up to 8 user-programmed Style Pre-
sets. Unlike other Groups, the Style Groups can-
not be “switched” - they must be loaded to their
original locations in memory. For example, Group
A
B
