GEM GPS3600 User Manual

○○○○○○○○○○○○○○○○○○○○○○
Edit Style 5•25
○○○○○○○○○○○○○○○○○○○○○○
Edit Style 5•25
EVENTS TABLE AND RELATVE PARAMETERS
STATUS VALUE 1 VALUE 2 VALUE 3 GATE
Note Note name Key On Velocity Key Off Velocity Note Length
expressed as the
Sequencer resolution
(q=192) [0 … 63323]
Program Program change Bank Select MSB Bank Select MSB
Change message. The PC message. To select message. Not
contained in the tracks the PS/GPS banks, necessary to select
and shown in the use numbers 1 … 16 the PS/GPS sounds
Microscope has [1 … 128] [1 … 128]
priority over the PC
recorded in the
Preset. [1 … 128]
Control Type of Control Control Change
Change Change (or MIDI Value
controller).
Example: CC00 =
BankSelect MSB,
CC32 = BankSelect
LSB, CC01 =
Modulation, CC07 =
Volume
[1 … 128]
Pitch Value of LSB (Least Value of MSB
Bend Significant Byte). (Most Significant
[0= Off, 1…127 = On] Byte). Effectifve
value of bending.
[0…63 = down
64 = neutral
65…127 = up]
Mono Channel
Touch Aftertouch intensity
[0 … 127]
Poly Note to which Note Aftertouch
Touch Aftertouch is applied. intensity.
[C–1 … G9] [0 … 127]
EVENTS TABLE AND RELATVE PARAMETERS
STATUS VALUE 1 VALUE 2 VALUE 3 GATE
Note Note name Key On Velocity Key Off Velocity Note Length
expressed as the
Sequencer resolution
(q=192) [0 … 63323]
Program Program change Bank Select MSB Bank Select MSB
Change message. The PC message. To select message. Not
contained in the tracks the PS/GPS banks, necessary to select
and shown in the use numbers 1 … 16 the PS/GPS sounds
Microscope has [1 … 128] [1 … 128]
priority over the PC
recorded in the
Preset. [1 … 128]
Control Type of Control Control Change
Change Change (or MIDI Value
controller).
Example: CC00 =
BankSelect MSB,
CC32 = BankSelect
LSB, CC01 =
Modulation, CC07 =
Volume
[1 … 128]
Pitch Value of LSB (Least Value of MSB
Bend Significant Byte). (Most Significant
[0= Off, 1…127 = On] Byte). Effectifve
value of bending.
[0…63 = down
64 = neutral
65…127 = up]
Mono Channel
Touch Aftertouch intensity
[0 … 127]
Poly Note to which Note Aftertouch
Touch Aftertouch is applied. intensity.
[C–1 … G9] [0 … 127]
○○○○○○○○○○○○○○○○○○○○○○
Edit Style 5•25
○○○○○○○○○○○○○○○○○○○○○○
Edit Style 5•25
EVENTS TABLE AND RELATVE PARAMETERS
STATUS VALUE 1 VALUE 2 VALUE 3 GATE
Note Note name Key On Velocity Key Off Velocity Note Length
expressed as the
Sequencer resolution
(q=192) [0 … 63323]
Program Program change Bank Select MSB Bank Select MSB
Change message. The PC message. To select message. Not
contained in the tracks the PS/GPS banks, necessary to select
and shown in the use numbers 1 … 16 the PS/GPS sounds
Microscope has [1 … 128] [1 … 128]
priority over the PC
recorded in the
Preset. [1 … 128]
Control Type of Control Control Change
Change Change (or MIDI Value
controller).
Example: CC00 =
BankSelect MSB,
CC32 = BankSelect
LSB, CC01 =
Modulation, CC07 =
Volume
[1 … 128]
Pitch Value of LSB (Least Value of MSB
Bend Significant Byte). (Most Significant
[0= Off, 1…127 = On] Byte). Effectifve
value of bending.
[0…63 = down
64 = neutral
65…127 = up]
Mono Channel
Touch Aftertouch intensity
[0 … 127]
Poly Note to which Note Aftertouch
Touch Aftertouch is applied. intensity.
[C–1 … G9] [0 … 127]
EVENTS TABLE AND RELATVE PARAMETERS
STATUS VALUE 1 VALUE 2 VALUE 3 GATE
Note Note name Key On Velocity Key Off Velocity Note Length
expressed as the
Sequencer resolution
(q=192) [0 … 63323]
Program Program change Bank Select MSB Bank Select MSB
Change message. The PC message. To select message. Not
contained in the tracks the PS/GPS banks, necessary to select
and shown in the use numbers 1 … 16 the PS/GPS sounds
Microscope has [1 … 128] [1 … 128]
priority over the PC
recorded in the
Preset. [1 … 128]
Control Type of Control Control Change
Change Change (or MIDI Value
controller).
Example: CC00 =
BankSelect MSB,
CC32 = BankSelect
LSB, CC01 =
Modulation, CC07 =
Volume
[1 … 128]
Pitch Value of LSB (Least Value of MSB
Bend Significant Byte). (Most Significant
[0= Off, 1…127 = On] Byte). Effectifve
value of bending.
[0…63 = down
64 = neutral
65…127 = up]
Mono Channel
Touch Aftertouch intensity
[0 … 127]
Poly Note to which Note Aftertouch
Touch Aftertouch is applied. intensity.
[C–1 … G9] [0 … 127]
