Page 99
ITEM QTY. DESCRIPTION
1 1 ENGINE 432CC GASEOUS
2 2 SCREW, HHFCS M6·1 X16 G8.8
3 1 NUT HEX LOCK M5-0.8 NYINS ZINC
4 1 BRACKET, 432CC GOVERNOR ADJUST
5 1 SPRING, GOV MAIN LV432 EHSB
6 1 BOLT, GOV ADJUST M5
7 1 GASKET, AlRBOX
8 2 ASSEMBLY, KNOB, M6 ORANGE
9 1 AlRBOX COVER, 432CC OHV
10 1 ELEMENT, AIR FILTER
11 1 ASSY AIRBOX W/CHOKE 432CC OHV
12 1 WASHER NYLON .257
13 2 SCREW PPHM #40-4O X3/8 SEMS
14 1 CHOKE ROD 432CC EHSB
15 1 SPRING, CHOKE RETURN
16 1 COTTER PIN 1/4" SHAFT .091 WI
17 1 SOLENOID, 6VDC MOLEX
18 1 BREATHER HOSE 432CC OHV
19 2 WASHER FLAT 1/4-M6 ZINC
20 4 WASHER LOCK M6-1/4
21 1 SCREW HHC M6-1.0 X35 C8.8 BLK
22 2 INTAKE MOUNTING ROD 432CC
23 2 NUT FLANGE M6-1.0 NYLOK
24 2 CLAMP HOSE BAND .75"
ITEM QTY. DESCRIPTION
25 1.8FT LPG HOSE ASSEMBLY
26 1 NUT HEX LOCK M3-0.5 NY INS
27 1 BALL STUD,10 MM
28 1 ASSY THROTTLE ROD
29 1 GASKET INTAKE 432CC OHV
30 1 ASSY THROTTLE BODY 432CC OHV
31 1 GASKET INTAKE 432CC OHV
32 1 HOSE 3.18ID SAE J30R7 METRIC
33 1 SPRING, GOV, ANTI-LASH
34 1 SCREW HHFC M6-1.0 X12 G8.8
35 1 TIE WRAP, BEADED RELEASABLE
36 1 ASSY HOSE OIL DRAIN 6.0" LG ORG
37 1 BARBED STR 3/8NPT X3/8 VS
38 1 CLAMP, HOSE OETIKER STPLSS 18.5
39 2 NUT HEX 1/4-20 STEEL
40 1 CONTACTER, STARTER SOLENOID
41 2 SCREW, HHTT M6X1.0 X10
42 1 NUT HEX M6-1.0 G8 CLEAR ZINC
43 2 WASHER LOCK #8-M4
44 2 NUT HEX #8.32 STEEL
45 3 BOOT, VINYL STARTER·SOLENOID
46 1 JET REGULATOR 4.38 (LP)
1 JET REGULATOR 5.00 (NG)
47 1 O-RING 5 X 1.5 NITRILE 70
DISASSEMBLY
PART 5
Section 5.2
Exploded Views
