Generac Power Systems CorePower User Manual

ENGINE/DC CONTROL
PART 4
Page 61
Section 4.4
Troubleshooting Flowcharts
FUSE BLOWS WHEN
PLACED IN “AUTO”
OR “MANUAL”
Problem 25 – 7.5 Amp Fuse (F1) Blown
TEST 74 & 75 –
CHECK CRANKING
AND RUNNING
CIRCUITS
Problem 26 – Generator Will Not Exercise
TEST 72 – TEST
EXERCISE
FUNCTION
REPLACE PRINTED
CONTROLLER
REPAIR OR REPLACE
REPLACE CHARGER
Problem 27 – No Battery Charge
TEST 76 – CHECK
BATTERY CHARGER
SUPPLY VOLTAGE
TEST 77 – CHECK
BATTERY CHARGER
OUTPUT VOLTAGE
TEST 78 – CHECK
WIRE 0/15B
GOOD
GOOD
BAD
REPAIR OR
REPLACE
BAD
BAD
NO BATTERY
SUPPLY VOLTAGE
