Page 91
DISASSEMBLY
PART 5
Section 5.2
Exploded Views
ITEM QTY. DESCRIPTION
1 1 COVER,.CUSTOMER CONNECT BOX
2 1 BOX CUSTOMER CONNECT
3 1 BUSHING, SNAP SB-1000-12
4 8 WASHER, LOCK M5
5 2 WASHER FLAT M5
6 2 SCREW, HHC M5-0.8 x 16 G8.8
7 1 AVR
8 1 BUSHING SNAP SB-500-6
9 1 SCREW HHC M6-1.0 X 20 C8.8
10 3 BUSHING SNAP SB-687-8
11 1 TERM BLOCK 3P UL 12-20AWG LBL
12 1 TERM BLOCK 3P UL 12-20AWG
13 4 SCREW PPHM M3-0.5 x 30
14 1 PLATE CONDUIT CUST. CONNECT
15 2 SCREW PPPH #8-16 x .66" BZC
16 1 PLATE, DEAD FRONT CUST. CONNECT
17 1 WASHER, LOCK EXT #10 STL
18 1 SCREW HHTT M5-0.8 x 10 BP
ITEM QTY. DESCRIPTION
19 1 EYE HASP CNTRL PNL 2008 HSB
20 1 SCREW PPPH #10 X 1/2" LG
21 1 CB 0030A 2P 240V 5 BQ2 LB
22 2 SCREW HHC M5-0.8 X 12 C8.8
23 1 BRKT CB MTG BACK
24 2 GROUND BAR (5)4-14 AWG CONN
25 4 SCREW HHC Ml1.-0.7 X 25 SEMS
26 2 NUT HEX M6-1.0 G8 CLEAR ZINC
27 2 WASHER LOCK M6-1/4
28 4 SCREW PPHM M5-0.8 X 12 ZNC
29 1 ASSY CTR PNL 2010 CORE POWER
30 1 BOX CONTROL PANEL
31 1
BATTERY CHARGER 13.4VDC 2.5A CP
HSB 32
32 1 WASHER FLAT 1/4-M6 ZINC
33 1 HARNESS, 7 KW (NOT SHOWN)
34 1 WIRE, DEADFNT TO GND (NOT SHOWN)
35 1 WIRE, GND TO DEADFNT (NOT SHOWN)
36 1 WIRE, BUSBAR TO GND (NOT SHOWN)
