Page 93
ITEM QTY. DESCRIPTION
1 5 NUT FLANGE 5116·18 NYLOK
2 1 EARTH STRAP 3/ax 3/8
3 1 THERMAL SWITCH 255 F
4 2 SCREW PPHM M3.o.5 X 6 SEMS
5 1 DUCT ALTERNATOR INTAKE
6 4 SCREW HHTT M5-0.8 X12 BP
7 1 GROMMET SLEEVE WIO MEMBRANE
8 1 BELLOWS, ALTAIR IN
9 1.8 FT TAPE ELEC UL FOAM 1/8 X112
10 1 ASSY SPACER RING WI DOWEL PINS
11 1 RTR ASSY 7KW ECON VERT
12 1 STR ASSY 7KW ECON VERT
13 1 BEARING CARRIER ECON
14 1 BRUSH HOLDER
15 1 SCREW HHTT M5-0.8 X16
16 7 WASHER LOCK M8·5116
17 4 SCREW IHHC M8·1.25 X315 C8.8
18 1
FAN•CURVEDBLADE,203.5OD
19 1 GASKET, ALT AIR OUT
20 1 WASHER FLAT .406ID X1.620D
21 1 SCREW IHHC 5116·24 X 12 G8 ZP
22 2 SCREW HHTT M8-1.2 X16 YC
23 1 MUFFLER, ECONOMY HSB
24 2 SCREW SHC 5118-18 X3/4
ITEM QTY. DESCRIPTION
25 1 EXHAUST GASKET
26 13 SCREW HHTT M6-1.0 X10 VEL CHR
27 1 EXHAUST SHIELD ALTERNATOR
28 4 VlB MNT 1.3axl.0X5116-18 MXM
29 1 WASHER LOCK SPECIAL 5116
30 1 FRAME WELDMENT
31 2 SCREW HHTT M6-1.0 X20 ZINC
32 4 SCREW HHFC M6-1.0X 12 G8.8
33 1 EXHAUST SHIELD, RIGHT SIDE
34 1 EXHAUST SHIELD MUFFLER COVER
35 1 EXHAUST SHIELD, LEFT SIDE
36 1 EXHAUST SHIELD, ENG WRAPPER
37 1 CLAMP STLNNL .75 X.281 Z
38 1 OIL SUMP PLUG SMALL
39 1 OIL SUMP PLUG LARGE
40 1 WIRE, BRUSH POS #4 (NOT SHOWN)
41 1 WIRE, BRUSH NEG #0 (NOT SHOWN)
42 1 CABLE, SC TO SM (NOT SHOWN)
43 2 WIRE, ENG TO GND (NOT SHOWN)
44 1 BATT POS. CABLE COREPOWER (NOT
SHOWN)
45 1 BATT NEG. CABLE COREPOWER (NOT
SHOWN)
46 1 WASHER FLAT 1/4-M6 ZINC
DISASSEMBLY
PART 5
Section 5.2
Exploded Views
