Page 95
ITEM QTY. DESCRIPTION
1 1 ASSY EXHAUST PANEL AIRBOX SIDE
2 1 BASE
3 1 ASSY FRONT PANEL BISQUE
1 ASSY FRONT PANEL GREY
4 4 BRACKET, CORNER POST
5 5 SCREW HHFC M6-1.0X 12
6 3 EXTRUSION, ENCLOSURE CORNER
7 1 ASSY. EXHAUST PANEL CONTROL PANEL
SIDE
8 4 ROOF FASTENER
9 4 SPRING CORE POWER ROOF
10 4 SUPPORT, ROOF LATCH
11 1 ROOF WITH INT DUCT
12 1 ASSY REGULATOR 7KWVERT HSB
13 1 HOSE, REGULATOR VENT
14 2 CLAMP HOSE BAND .66
ITEM QTY. DESCRIPTION
15 1 ASSY., SNAP BARB W/SCREEN
16 1 GROMMET,38.1 CROSS SLIT W/HOLE
17 1 ASSY., BACK PANEL
18 4 WASHER, FLAT1/4-M6
19 4 WASHER, LOCK M6-1I4
20 4 SCREW, BHSC M6-1.0X16ZP
21 1 GASKET, AIRBOX PANELIROOF
22 1 GASKET, BLOWER HOUSING
23 1 GASKET, ENGINE AIR IN BACK
24 1 GASKET, ENGINE AIR IN FRONT
25 2 SCREW, HHTI M6-1.0X12 ZINC
26 1 WIRE, ENG TO CNRPST
27 1 CRNR SUPPORT W/GND HOLE
28 2 LUG SLDLSS #2-#8X17I64 CU
29 2 MAT, EXHAUST ENCLOSURE, INSIDE
DISASSEMBLY
PART 5
Section 5.2
Exploded Views
