Page 97
ITEM QTY. DESCRIPTION
1 1 SHROUD COVER, FAN
2 3 STUD, LIFTING
3 1 STUD, LIFTING
4 1 SCREEN, FAN
5 1 COIL ASSY., IGNITION
6 2 BOLT, FLANGE 6X25
7 1 FLYWHEEL, COMPLETE
8 1 FAN, COOLING
9 1 PLATE, FAN
10 1 NUT, SPECIAL M16
11 1 CLIP, WIRE HARNESS
15 1 CRANKCASE, UPPER
16 1 STARTER
17 2 BOLT, FLANGE, M8X80
18 1 NUT, FLANGE M6
19 1 BOLT, GOVERNOR ARM
20 1 ARM,GOVERNOR
21 1 PIN, LOCK
22 1 SEAL,OlL
23 1 WASHER
24 1 SHAFT, GOVERNOR ARM
25 2 BEARING, EDDP GROOVE, BALL
26 1 O-RING, 12X2.5
27 1 BEARING, EDDP GROOVE, BALL
28 3 BOLT, FLANGE 6X12
29 1 CAP, BREATHER CHAMBER
30 1 GASKET, BREATHER CHAMBER
31 1 OIL SEAL
32 1 VALVE, REED
33 1 CAP ASSY, NOISE SUPRESS
DISASSEMBLY
PART 5
Section 5.2
Exploded Views
