Assembly
1. Open UAV transport case,
Take out UAV folding rack and place it on a at surface.
Take out fuselage from transport case and place it on UAV folding rack.
2. Remove the top cover by moving the pin, as shown in the picture.
UAV top cover removing
3. Take largest mounting rods (610 mm) and insert them in holes in fuselage.
Mounting rods inserting
13
