Battery discharge speed depends on UAV motor speed. The autopilot system is change
speed level depends on telemetry sensors and UAV ight task. For example, for mini-
mizing of battery discharge you can create eld of aerial survey with minimum points
of UAV rotate in ight.
Battery Heating (for «Arctic» Battery)
«Arctic» batteries are marked by snowake on the body. That batteries have more
using temperature range from -40 to +20 °C.
Press Control button (1) more than 2 seconds to activate temperature holding mode
(range: from +20 to +30°С) for 30 minutes. Status LED (3) will change color to
orange. LED status bar (3) will show remaining temperature holding time (3 min for
each LED). Press Control button (1) again to turn temperature holding off.
The table below shows LED number connection with remaining time of temperature
holding .
Remining Time of Battery Temperature Holding
LEDs Remaining Time, min
I (1) 3
II (2) 6
III (3) 9
IIII (4) 12
IIIII (5) 15
IIIIII (6) 18
IIIIIII (7) 21
IIIIIIII (8) 24
IIIIIIIII (9) 27
IIIIIIIIII (10) 30
Battery temperature holding mode is activated automatically, when you connect ex-
ternal heating source (battery of auto) to balance port (2) by balancing cable. Status
LED will lights orange, and battery will change mode to temperature holding for
30 minutes. Repeat balance cable connection if you need more time of temperature
holding.
We recommend to turn auto engine on to avoid full discharge of auto’s battery.
