9. Put the salient in parachute compartment’s cover rear in UAV body’s slot and hold
down the cover.
Lock the cover by servo horn.
Check that the parashute compartment cover can opens. To do that just
rotate servo horn. The parashute rigging lines must be free.
10. Close and lock the cover by servo horn.
Fixing the parachute compartment’s cover
Do not rotate servo horn when power is on!
26
