48
Auto Start: Automatically starts connections with IP devices after GV-Recording Server
is started.
[Multicast] The multicast provides a mechanism for sending a single video and audio stream
to a group of hosts.
Network Interface Card: Select a Network Card to run multicast on a different network.
Since the multicast can take a lot of bandwidth when enabled, separating it from the main
network is advised whenever possible.
Multicast: Select this option to enable the multicast settings and send video and audio
streams to the multicast group.
• Update Period: Specify the time length in second between each update of multicast
streams.
• IP Address: Type the IP address used for multicasting. Only the hosts with the
same multicast IP can receive the multicast streams. The default IP address is
224.1.1.2.
• Port: Type the port number used for multicasting. The default port number is 8300.
• Password: Select this option and type a password to secure multicast streams. The
hosts in the multicast group will need to enter the password before accessing video
and audio streams.
To see how to connect to GV-Recording Server using Multicast, see 7.3 Connecting with
Multicast.
[RTSP] You can connect to IP devices through RTSP protocol if the protocol is supported by
the IP device.
RTSP/TCP Port: The default port number is 554.
RTP/RTCP/UDP Port: The default port range is 17300 to 17380.
Max. Connection(s)(1~20): Specify the maximum number of RTSP connections. The
default value is 20 channels.
Note: Only VLC media player and QuickTime Player are supported for streaming H.264
video via RTSP protocol.
For more details on how to connect to IP devices through RTSP, see Appendix B. RTSP
Protocol Support.
