94
7.6 Connecting with the GV-Mobile Server
You need to configure the GV-Mobile Server to access video streaming from the GV-
Recording Server.
Note: The GV-Recording Server is only compatible with GV-Mobile Server of version 1.3 or
later.
1. Select a camera from the left menu and click the Stream Source tab. This window
appears.
Figure 7-15
2. Type a name to describe the camera in the Camera Name field (Max. 31 characters).
3. Configure the connection settings.
A. Select GV-Recording Server for Brand.
B. Type the Command Port, IP Address, User Name and Password of the GV-
Recording Server. The default command port for GV-Recording Server is 11000.
C. Type the camera number for live viewing in Source Camera. The default setting is
1.
4. If your GV-IP device supports dual streams, GV-Mobile Server connects to stream 1 by
default. To connect to stream 2, select Connect to stream 2.
