GERBERplotter MP Series User Manual
English
Modiers
STOP
User Manager does not send jobs after a STOP modier.
If the STOP modier is deleted or moved to another location, the next available job is sent.
Clean
Use the CLEAN modier to clean the print heads. It is recommended that you use this at the start of the day. When
User Manager encounters a CLEAN modier, User Manager sends a small print job to the plotter to clean the print
heads.
Add text to print
Add text to print lets you send text to the queue. You can change the text thickness, size, and orientation. Only
standard HPGL characters are supported.
CUT / CUT PAUSE / CUT PLUS
The following pictures of modiers are added to the jobs queue.
1
Use the CUT PAUSE modier to print a cut indicator between markers. When User Manager nds a CUT
PAUSE modier in the print queue, the plotter prints a dashed line after that job to show where to cut the paper.
The next available job is sent to the plotter. When the dashed line indicating a cut reaches the cutting zone, print-
ing stops. This lets you cut and remove the job.
When the paper roll has been cut and the job removed, press PRINT/PAUSE to advance the paper so you can
fasten it to the take-up bar, using the side and center clips. Press PRINT/PAUSE to start printing.
2
Use the CUT PLUS modier to stop printing to cut the paper. When User Manager nds a CUT PLUS modier
in the print queue, the plotter prints a dashed line after that job, advances the paper to the cut zone, and stops
printing. This lets you cut and remove the job.
3
Use the CUT modier to print a cut indicator between markers. When User Manager nds a CUT modier in the
print queue, the plotter prints a dashed line after that job to show where to cut the paper. The next jobs are sent to
the plotter, which continues printing and does not stop for cutting.
