Gerber Technology GERBERplotter MP Series

28
GERBERplotter MP Series User Manual
English
Electronic assembly
Step 14 of 17
1
Place the electronic panel connections hub into the lateral leg
connection hole (CH).
2
Turn and push the connection panel to clip it in place.
Install the electronic panel.
1
2
CLICK
CLICK
CLICK
CLICK
CN319 (box 3)
3a
3b
3c
3d
14
CH
