System Preparation and Use 77
The number data is supplied in the file
GRIDNUMB.RTP
.
2
GRIDNUMB.RTP
To engrave the grid
1.
In ART Path, choose Open from the File menu.
2.
Highlight Router Files under List Files of Type to open
ENGRGRID.RTP
. Click on OK.
3.
In the Setup menu, select Start/End position.
4.
Set the Start/End position to start and end the machine at the
lower left.
5.
Click on OK.
6.
Install the .020 engraving bit supplied in the tool kit.
7.
On the ARC station, press Z INIT once to unlock the Z axis.
8.
Place the tool height gage on the surface of the mats under the
bit. Use the Z axis knob to lower the tool until it just touches
the gage.
9.
Press Z INIT once. This lifts the Z axis once and locks it. The
tool is now initialized to the table surface.
10.
Using the arrow keys, move the carriage to the extreme lower
left corner (absolute 0,0 or the orientation point) of the table.
