Gerber Dimension 200 - Page 78

78
Dimension 200
11. In ART Path, click on Output. The Job Output dialog box
appears. (Make sure that no pre-position moves have been
entered.)
12. Click on Rout.
13. Press START/STOP three times to begin grid milling. This
displays the header and tool messages and begins routing.
To engrave the grid numbers
Note: Use the same .020 engraving bit as above.
1. In ART Path, choose Open from the File menu.
2. To engrave the numbers, highlight Router Files under List
Files of Type to open
GRIDNUMB.RTP
. Click on OK.
3. In the Setup menu, select Start/End position.
4. Set the Start/End position to start and end the machine at the
lower left.
5. Click on OK.
6. On the ARC station, press Z INIT once to unlock the Z axis.
7. Place the tool height gage on the surface of the mats under the
bit. Use the Z axis knob to lower the tool until it just touches
the tool height gage.
8. Press Z INIT once. This lifts the Z axis once and locks it. The
tool is now initialized to the table surface.
9. Using the arrow keys, move the carriage to the extreme lower
left corner (absolute 0,0 or the orientation point) of the table.
10. In ART Path, click on Output. The Job Output dialog box
appears. (Make sure that no pre-position moves have been
entered.)
11. Click on Rout.
