G5 – Owner‘s Manual | 71
Controls the length of the LFO waveform period and thus the
frequency of the generated sweep.
Controls the intensity of the panning effect. Values range from 0
(equals to mono) to 127 (full alternation between the extreme
values 63L and 63R).
This parameter pixelates the audio signal and thus reduces the
resolution of the signal (vertical direction, bit depth).
Values: 24 (no reduction), 1 bit up to 16 bits
Reduces the resolution of the wave period by lowering the sam-
pling rate. (horizontal direction, quality) Values are defined as
reduction factor and range from 1(no reduction) to 16 (reduction
to 1/16 of the original sampling rate).
Bit Resolution and Down Sampling are prone to increasing the
amount of high frequencies in the output signal. Brightness adjusts
the frequency of a low pass (high cut) filter with a transition steep-
ness of 12 dB. Low control positions correspond to low filter fre-
quencies and less treble, while high control positions lead to high
filter frequencies and thus filter out less treble.
